ℹ️ Edit: An updated version, with more options included, exists here.
When building serverless apps on AWS today there's a couple of different toolkits available that helps you develop, test and deploy your project. Serverless Framework was the king for a long time but both AWS SAM and the CDK have been increasing in popularity lately. But which one is the best to use in a new project and what's the difference between them anyway. After all, they're all just tools to produce Cloudformation templates anyway, right?
To get an understanding of the strengths and disadvantages of each option, I decided to build an identical example application across all three and compare the approaches.
By the end of this post, I hope you'll have a basic understanding of the Serverless Framework, AWS SAM, and the CDK and that you'll be able to make an educated choice on what'll suit your next project best based on your needs and preferences.
Our Example Application
To keep it interesting, the app we're using to showcase each framework certainly isn't your typical ToDo-app - it's a ToDont-app. A user can send a POST request to an API Gateway describing something they really shouldn't do, a Lambda function takes the ToDont-item and puts it on an SQS queue that acts as a buffer before finally another Lambda function consumes the buffer queue, pretends to do some heavy processing on the item and persists it in a DynamoDB table.
The application architecture is simple enough to easily comprehend but "complex" enough to resemble an actual app. To keep the code compact and readable, best practices and common sense have sometimes had to be omitted. All configs are complete and fully functional however and if you want to play around with the examples and deploy the apps yourself, you can find the code and the full examples here.
Our POST Lambda function looks like this
const { SQS } = require('@aws-sdk/client-sqs');
const sqs = new SQS();
const handler = async (event) => {
console.log('event', event);
const { id, title } = JSON.parse(event.body);
await sqs.sendMessage({
QueueUrl: process.env.QUEUE_URL,
MessageBody: JSON.stringify({
id,
title,
})
});
return {
statusCode: '200',
};
};
module.exports = { handler };
the Process Lambda looks like this
const { DynamoDB } = require('@aws-sdk/client-dynamodb');
const { marshall } = require("@aws-sdk/util-dynamodb");
const ddb = new DynamoDB();
const handler = async (event) => {
console.log('event', event);
const tasks = event.Records.map((record) => {
const { id, title } = JSON.parse(record.body);
return ddb.putItem({
TableName: process.env.TABLE_NAME,
Item: marshall({
title,
id,
}),
});
});
return Promise.all(tasks);
};
module.exports = { handler };
Prerequisites
If you want to follow along and deploy the apps, please note the following:
Each of the comparisons below assumes that you've installed the following packages as dependencies in your project
@aws-sdk/client-dynamodb
@aws-sdk/util-dynamodb
@aws-sdk/client-sqs
While Yarn is used as the package manager & script runner below you could of course use NPM instead with the corresponding commands.
All of the examples assume that you've got an AWS credentials default profile configured
Serverless Framework
Serverless Framework ("Serverless" below) has been around for a long time now and has long been the preferred framework for a large part of the community. It's a simple tool that abstracts away and simplifies many of the nastier parts of CloudFormation and comes packed with features to simplify testing and deployment of your app.
The preferred way to run the Serverless CLI is to install it as a (dev)dependency in your project by running yarn add serverless -D and then all that's missing is a serverless.yml file which is used to define your application and its infrastructure. You can find the full configuration reference here but in short, the serverless.yml consists of two parts:
Your Serverless Framework configuration is used to describe your application stack, AWS environment, and lambda functions
Any additional infrastructure defined as CloudFormation resources, such as our DynamoDB table and SQS queue.
Here's how the serverless.yml for our application looks.
// serverless.yml
service: sls-todont
provider:
name: aws
region: eu-north-1
runtime: nodejs14.x
environment:
TABLE_NAME: ${self:custom.tableName}
QUEUE_URL: !Ref todontsQueue
iamRoleStatements:
- Effect: Allow
Action: sqs:sendMessage
Resource: ${self:custom.queueArn}
- Effect: Allow
Action: dynamodb:putItem
Resource: ${self:custom.tableArn}
custom:
tableName: ${self:service}-table
queueName: ${self:service}-queue
tableArn:
Fn::GetAtt: [todontsTable, Arn]
queueArn:
Fn::GetAtt: [todontsQueue, Arn]
functions:
post:
handler: src/post.handler
events:
- http:
method: post
path: todonts
process:
handler: src/process.handler
events:
- sqs:
arn: ${self:custom.queueArn}
resources:
Resources:
todontsTable:
Type: AWS::DynamoDB::Table
Properties:
TableName: ${self:custom.tableName}
AttributeDefinitions:
- AttributeName: id
AttributeType: S
KeySchema:
- AttributeName: id
KeyType: HASH
BillingMode: 'PAY_PER_REQUEST'
todontsQueue:
Type: AWS::SQS::Queue
Properties:
QueueName: ${self:custom.queueName}
Now to deploy our application, all we need to do is run yarn serverless deploy.
The Serverless CLI includes some utility features that can be used to print or tail the logs of a deployed function by running yarn serverless logs --function process [--tail] or even invoke the function with yarn serverless invoke --function process. Most of the time during development, however, you're not going to be invoking the function. Instead, you'll let Serverless emulate and run the functions locally and you can do that by running yarn serverless invoke local --function post.
➕ Pros
Large & helpful community
The plugin ecosystem
Simple configuration with neat variable support
Great debugging and testing utilities
➖ Cons
Most apps will need to resort to CloudFormation definitions for some parts of the infrastructure
Hard to share configuration and components
Only YAML configurations. It's technically supported to write the configuration in JS but the documentation for it is close to non-existent
I've seen a lot of devs struggle with understanding where the line between Serverless configuration and CloudFormation configuration actually or why they have to change the syntax in the middle of the file
Resources:
Get started with Serverless Framework
Serverless Stack tutorial for deplying a production Serverless app
AWS SAM
Much like Serverless Framework, SAM (or the Serverless Application Model) is a combination of an abstraction layer to simplify CloudFormation and a CLI with utilities to test and deploy your app.
Here's the official install instructions for the SAM CLI which is installed globally on your system. SAM uses a samconfig.toml file to describe information about your app, such as the name and where and how it should be deployed, and a template.yml file to describe the actual resources your app will use.
The template.yml format follows the CloudFormation template anatomy templates but with a few added fields. Let's have a look:
// template.yml
AWSTemplateFormatVersion: 2010-09-09
Transform: AWS::Serverless-2016-10-31
Description: sam-todonts
Globals:
Function:
Runtime: nodejs14.x
Environment:
Variables:
QUEUE_URL:
Ref: TodontsQueue
TABLE_NAME:
Ref: TodontsTable
Parameters:
TableName:
Description: Name of DynamoDB table
Type: String
Default: sam-todonts-table
QueueName:
Description: Name of SQS queue
Type: String
Default: sam-todonts-queue
Resources:
PostFunction:
Type: AWS::Serverless::Function
FunctionName: sam-todonts-post
Properties:
Handler: src/post.handler
Events:
Post:
Type: HttpApi
Properties:
Path: /todonts
Method: post
Policies:
- SQSSendMessagePolicy:
QueueName:
Fn::GetAtt: [TodontsQueue, QueueName]
ProcessFunction:
Type: AWS::Serverless::Function
Properties:
Handler: src/process.handler
Events:
SQSQueueEvent:
Type: SQS
Properties:
Queue:
Fn::GetAtt: [TodontsQueue, Arn]
Policies:
- DynamoDBWritePolicy:
TableName:
Ref: TodontsTable
TodontsTable:
Type: AWS::DynamoDB::Table
Properties:
TableName: sam-todonts-table
AttributeDefinitions:
- AttributeName: id
AttributeType: S
KeySchema:
- AttributeName: id
KeyType: HASH
BillingMode: PAY_PER_REQUEST
TodontsQueue:
Type: AWS::SQS::Queue
Properties:
QueueName: sam-todonts-queue
The configuration is a bit verbose but luckily the CLI can help you with a place to start by running sam init and answering a few questions about what your planning to build.
We can generate the samconfig.tomlfile and deploy at the same time by running sam deploy --guided.
Again, much like the Serverless Framework CLI, SAM comes loaded with utility features to test and debug your app. sam local invoke [functionName] can be used to run a Lambda function, or you can start a local HTTP server that hosts your function by running sam local start-api. You can also easily fetch the logs from a deployed function by running sam logs --name [functionName].
The great thing about separating the definition of the app and how the app is built in two different files is that the template.yml file can be written very generically so that it can be shared and re-used, you'll just have a different samconfig.toml in each project. SAM also integrates very well with CodeBuild to enable blue-green deployments.
➕ Pros
Enables sharing & re-use of templates
Well integrated with AWS build pipelines
Great debugging and testing utilities
Can be combined with CDK
➖ Cons
Resources:
Getting started with AWS SAM
Serverless Application Repository
Serverless Patterns Collection
AWS CDK
The AWS Cloud Development Kit (CDK) isn't purely a tool for creating serverless apps, rather it's a full-blown infrastructure-as-code framework that allows you to use code, not config, to define your application.
You can install the CDK CLI by running yarn global add aws-cdk and then generate a starter project by running cdk init app --language --language typescript. There's a bunch of project configuration files and boilerplate that's generated when you run the init command but let's have a look at how the lib/cdk-stack.ts file looks like after we've described our ToDont-app in it.
import * as cdk from '@aws-cdk/core';
import lambda = require('@aws-cdk/aws-lambda-nodejs');
import sqs = require('@aws-cdk/aws-sqs');
import dynamodb = require('@aws-cdk/aws-dynamodb');
import { ApiEventSource, SqsEventSource } from '@aws-cdk/aws-lambda-event-sources';
import { Runtime } from '@aws-cdk/aws-lambda';
export class CdkStack extends cdk.Stack {
constructor(scope: cdk.Construct, id: string, props?: cdk.StackProps) {
super(scope, id, props);
const dynamoTable = new dynamodb.Table(this, 'cdk-todonts-table', {
tableName: 'cdk-todonts-table',
partitionKey: { name: 'id', type: dynamodb.AttributeType.STRING },
});
const sqsBuffer = new sqs.Queue(this, 'cdk-todonts-queue', {
queueName: 'cdk-todonts-queue',
});
const processLambda = new lambda.NodejsFunction(this, 'cdk-todonts-process', {
runtime: Runtime.NODEJS_14_X,
handler: 'handler',
entry: 'src/process.js',
events: [new SqsEventSource(sqsBuffer)],
environment: {
TABLE_NAME: dynamoTable.tableName
}
});
dynamoTable.grantWriteData(processLambda);
const postLambda = new lambda.NodejsFunction(this, 'cdk-todonts-post', {
runtime: Runtime.NODEJS_14_X,
entry: 'src/post.js',
handler: 'handler',
events: [new ApiEventSource('POST', '/todonts')],
environment: {
QUEUE_URL: sqsBuffer.queueUrl,
}
});
sqsBuffer.grantSendMessages(postLambda);
}
}
The basic building blocks of a CDK application are called constructs which represent a "cloud component", whether that's a single service instance such as an SQS Queue or a set of services encapsulated in a component. Constructs can then be shared and reused between projects and there's a fantastic community that has built a massive collection of high-quality components for you to use. Having the app and its infrastructure described fully in code also means that we can write actual tests against our setup - pretty darn cool, huh?
Before we can deploy the app for the first app, we need to bootstrap the AWS environment (account & region combination) to provision some resources that the CDK uses to deploy the app. After that, we can run cdk deploy to deploy our application.
The CDK CLI doesn't bring the same utility around testing and debugging as SAM and Serverless does but it is possible to use the SAM CLI together with the CDK to help bridge the gap. There's also a newcomer on the block, Serverless-Stack, an extension of the CDK, that brings a lot of testing utility and serverless specific constructs.
➕ Pros
➖ Cons
- Need to use another tool, such as SAM or the AWS CLI, if you want to invoke or print the logs of a deployed function.
Resources:
Getting started with the AWS CDK
CDK Patterns
CDK Day
Wrapping Up
There's a lot that's happening in this space at the moment and while I think these are the three most prominent players right now, alternatives popping up left and right. Each framework has its own strengths and benefits and there's rarely a wrong or right when choosing which one will work best in your project.
Please let me know in the comments which one is your favorite and why!
